Toyota Hilux Prado Surf 1KZ-TE 3.0L Cylinder Head Complete

Complete 1KZ-TE Cylinder Head — Ready to Install

Complete 1KZ-TE cylinder head assembly with camshaft, shim tappets with clearances set, valves, springs, retainers, seals, gaskets, and head bolts fitted. Professionally assembled and pressure tested. Suits Toyota Hilux, Prado and Surf with the 3.0L turbo diesel engine.

Fits: Toyota Hilux, Prado, Hilux Surf (1996–2006) — Engine code 1KZ-TE, 1KZTE, 3.0L 4-cylinder turbo diesel

Important: Two cylinder head versions exist for the 1KZ-TE engine — identified by your piston type. Early model pistons have a single large kidney-shaped valve relief and suit the cylinder head with valves sitting 1mm below the head face. Later model pistons have two distinct valve relief pockets and suit the cylinder head with valves flush with the head face — this is the most common version and the head we supply. Refer to the piston identification images below. Not sure which you have? After ordering we will contact you to confirm your version before dispatch.

What's Included:

• Complete cylinder head assembly with valves, springs & seals
• Camshaft installed with shim tappets — tappet clearances preset
• MLS head gasket (thickest specification)
• Torque-to-yield (TTY) stretch bolts (single-use)
• Complete head gasket set with all seals & O-rings
• ✓ Free Delivery: Available to most Australian addresses — Perth pickup also available

Key Specifications:

• Engine Code: 1KZ-TE / 1KZTE — 3.0L 4-cylinder turbo diesel
• Valve configuration: 8-valve SOHC
• Head gasket material: Multi-layer steel (MLS)
• Bolt type: Torque-to-yield (TTY) stretch bolts (single-use)
• Quality: Premium aftermarket
• ✓ Warranty: 12 months

Compatibility Guide

Guide only — please contact us if you are unsure.

• 1996–2002: Toyota Hilux Surf with 3.0L turbo diesel, engine code 1KZ-TE
• 1996–2002: Toyota Hilux with 3.0L turbo diesel, engine code 1KZ-TE
• 1996–2006: Toyota Landcruiser Prado with 3.0L turbo diesel, engine code 1KZ-TE

Order online or by phone. Pickup available in Perth (Midland) or fast dispatch from Melbourne.

Frequently Asked Questions

Why choose a complete assembled head?
Arrives ready to install — valves seated, tappet clearances set, camshaft fitted, and pressure tested. No machine shop required, saving time and labour cost.

Early vs later 1KZ-TE head — what’s the difference?
Identified by your piston. Early model pistons have a single large kidney-shaped valve relief (suits head with valves 1mm below face). Later model pistons have two distinct valve relief pockets (suits head with valves flush with face — most common, and what we supply).

Does this include gaskets and bolts?
Yes — a complete VRS head gasket set and TTY head bolt kit are included. One kit, ready to fit.
